Audio transformer, chassis mount, Driver, 600 ct:200 ct ohms, 145 Series

Features

• Small, economical, open, two hole horizontal bracket mount.
• Insulated, color coded flexible leads, 4" long minimum (143, 144 & 145 Series) or 3" long minimum (146 Series).
• For a similar, P.C. board mount version, refer to the 148 and 149 series.
• Frequency response 150 Hz. to 15 Khz. (+/- 1 db, reference 1000 Hz.)
• When operating at impedances below nominal, power capability and the frequency spectrum are proportionately lower, conversely, at higher impedances power capability and frequency spectrum will be proportionately higher.

Shipping Weight (0.05 kg) 0.1 lbs

Application   Driver

RoHS Compliant Yes

Output (mW) 135
