Drive belt with tangs for Princess Title Pages

Title page driving belt for Wurlitzer Princess series.

Original part number 0050330, this is an updated version for the Paternoster Motor Book.

Installation (needs editing) - click --> parts book PDF and see page 16:

• Take out the pages (#7) in groups left/right. (click for image)

• Remove lower cover (#12)

• Replace belt (#15) and replace bottom cover

• Using the buttons on the Motor Book/Paternoster to run the motor with no pages.
• Stop when 1 of the belt tangs is up in the front left and 1 on the back right.
• Then put the pages (#7) in making sure to set the 1 front page on the tang and the 1 rear page on the tang. Those 2 will look like they are midway to the opposite side of where they start.
• Once that is done they should all run fine.
• Customer noted the following: When I put the "PCB receive" back in, instead to trying to angle the bulb, I just put it so that it looked 90 degrees to the bar it is attached to. Then I put the pages back, making sure a front page and a back page were on their tangs. I flipped the switch and WALLA the lights came on and the pasternoster took off and aligned the pages properly. The red led turned constant red and I can advance and reverse as before. Had to play a few tunes just to check things out, all functions seem to be normal - Thanks to Robert L. for the note!
