Handheld Personal Scope

Oscilloscope:

• 40 MHz sampling rate
• Up to 12 MHz analog bandwith
• 0.1 mV sensitivity
• 5mV to 20V/DIV in 12 steps
• 50NS to 1 hour/DIV time base in 34 steps
• Ultra fast full auto set up option
• Adjustable trigger level
• X and Y position signal shift
• DVM readout
• Audio, power calculation (RMS and peak)
• dBm, dBv, DC, RMS ... measurements
• Signal markers for voltage and time
• Frequency readout (trough markers)
• Recorder function (roll mode)
• Signal Storage (2 memories)
• Backlit LCD
• Galvanically separated USB output for PC
• Data or bitmap download to PC
• Li-ion battery inside
• Autonomy: about 5 hours
• Worldwide charging adaptor included

Screen Modes:

• Normal screen
• Wide screen with DVM
• Normal screen with large DVM
• Wide screen with large DVM

USB PC Connection:

• Real time capture + screen capture
• USB connection to PC
• USB 2.0 and 1.1 compatible

General Information:

• Power supply
  • Li-ion battery: 7.4V / 1050mAh (inside)
  • Worldwide charging adaptor (included)
• Weight: 440g / 0.97lbs
• Dimensions: 110 x 175 x 40mm / 4.3 x 6.9 x 1.6"
