Motor

This New Old Stock motor is very similar to the one used in Interflip Dragon timing motor, faster than the Player Control Unit in the headboard though - that one is 25RPM.

Same make, speed (verify you want the 40RPM motor!), etc., however the shaft is longer and has a "D" cutout. The shaft can be shortened and then drilled for the wrist pin, or you can simply exchange the shafts - gears are all the same.

Original Dragon motor part number was Type 82.605.PDH. This motor is the same size and mount.

Price includes relubing, if you want to dismantle, clean, and relube the motor yourself then the price will be $125USD ($25USD refunded). These motors are New Old Stock but have sat for 40 years and we recommend relubing!

Motor specs:

• 50 Cycle (works fine at 60Hz)
• 24 VAC
• Inverse direction
• 40 RPM
• Type 82.605 5H
• Made in France by Crouzet
• Used in Recel's LADY LUCK and other games of that period
