TDA1543 Dual 16-bit DAC (economy version) I2S input format

TDA-1543 Integrated circuit Dual Op-Amp 8 pin DIP used in Stern/Sega Whitestar boards.

Note: These are pulls, but all have been tested in a Whitestar MPU and work properly.

Sega/Stern Reference:

• 100-5018-00

FEATURES
Low distortion
16-bit dynamic range
4 × oversampling possible
Single 5 V power supply
No external components required
No requirement for external de-glitcher circuitry due to fast settling output current
Adjustable bias current
Internal timing and control circuits
I2S input format: time multiplexed, two's complement, TTL.
