Belden 8429 two conductor and shield phono pickup wire per foot
Price is per foot. This was the tiny (32 gauge!) standard twin-lead shielded wire used in jukeboxes for the phono tone arm cartridge signal wire. Works for either Stereo or monaural pickups including ceramic, crystal, Zenith Cobra style (1100 through 1650), and magnetic versions.
Original specs of this Belden wire, that is rather hard to find these days as it is no longer in productoin:
- 2 conductor
- AWG 32 (7 x 40)
- Insulation thickness 0.009 inches
- Nominal OD 0.057 inches
- Conductor colour code Blk, Red
- Nom. Cap. between conductors (mmf/ft) 22
- Nom. Cap. condr. to other condr. & shield (mmf/ft) 38
Used in the following brands:
- AMI/Rowe jukeboxes
- Rockola jukeboxes
- Seeburg jukeboxes
- United jukeboxes
- Wurlitzer jukeboxes
Belden 8429 two conductor and shield phono pickup wire per foot
- Brand: Misc.
- Product Code: Belden_8429
- Availability: In Stock
-
$9.95 USD
